Makita DHR241Z varuosad
| Nr joonisel | Varuosa | SKU | Laos | Hind | Kogus |
|---|---|---|---|---|---|
| 001 | Cap 35 MAKITA 286263-4 | 286263-4 | Pole laos | 1.12 € | |
| 002 | Ring Spring 19 MAKITA 233940-9 | 233940-9 | Pole laos | 0.99 € | |
| 003 | Chuck Cover MAKITA 417629-9 | 417629-9 | Pole laos | 0.99 € | |
| 004 | Ring 21 MAKITA 257241-1 | 257241-1 | Pole laos | 0.99 € | |
| 005 | Guide Washer MAKITA 345187-4 | 345187-4 | Pole laos | 0.99 € | |
| 006 | Conical Compression Spring 21 MAKITA 233916-6 | 233916-6 | Pole laos | 0.99 € | |
| 007 | Hex Bolt M8 × 120 MAKITA 921923-8 | 921923-8 | Pole laos | 0.99 € | |
| 008 | Hex Washer MAKITA 345280-4 | 345280-4 | Pole laos | 0.99 € | |
| 009 | Grip Base MAKITA 417630-4 | 417630-4 | Pole laos | 1.40 € | |
| 010 | Grip 36 Assembly MAKITA 158057-6 | 158057-6 | Pole laos | 4.21 € | |
| 013 | Change Lever Assembly MAKITA 162245-9 | 162245-9 | Pole laos | 1.40 € | |
| 014 | Compression Spring 3 MAKITA 233459-8 | 233459-8 | Pole laos | 0.99 € | |
| 015 | Lock Button MAKITA 419192-8 | 419192-8 | Pole laos | 0.99 € | |
| 016 | O-Ring 17 MAKITA 213278-8 | 213278-8 | Pole laos | 0.99 € | |
| 017 | Gear Housing Assembly MAKITA 158216-2 | 158216-2 | Pole laos | 16.84 € | |
| 018 | Tapping Screw 4 × 35 mm MAKITA 266351-3 | 266351-3 | Pole laos | 0.99 € | |
| 019 | Needle Bearing Complete MAKITA 153290-5 | 153290-5 | Pole laos | 4.21 € | |
| 020 | Stop Ring E-3 MAKITA 961017-7 | 961017-7 | Pole laos | 0.99 € | |
| 021 | Guide Base MAKITA 417796-0 | 417796-0 | Pole laos | 0.99 € | |
| 022 | Compression Spring 4 MAKITA 233344-5 | 233344-5 | Pole laos | 0.99 € | |
| 023 | Lock Plate Complete MAKITA 163430-7 | 163430-7 | Pole laos | 1.40 € | |
| 024 | Tapping Screw 4 × 25 mm MAKITA 266374-1 | 266374-1 | Pole laos | 0.99 € | |
| 025 | Ring Spring MAKITA 233929-7 | 233929-7 | Pole laos | 0.99 € | |
| 026 | Washer 31 MAKITA 267460-1 | 267460-1 | Pole laos | 1.12 € | |
| 027 | Compression Spring 32 MAKITA 233401-9 | 233401-9 | Pole laos | 1.12 € | |
| 028 | Spur Gear 51 MAKITA 227109-5 | 227109-5 | Pole laos | 8.42 € | |
| 029 | Steel Ball 7.0 MAKITA 216022-2 | 216022-2 | Laos | 0.99 € | |
| 030 | Tool Holder Assembly MAKITA 158574-6 | 158574-6 | Pole laos | 28.06 € | |
| 031 | Flat Washer 28 MAKITA 267229-3 | 267229-3 | Pole laos | 0.99 € | |
| 032 | Sleeve 9 MAKITA 331769-8 | 331769-8 | Pole laos | 2.81 € | |
| 033 | Impact Bolt MAKITA 324669-9 | 324669-9 | Pole laos | 2.81 € | |
| 034 | Ring 10 MAKITA 324402-9 | 324402-9 | Pole laos | 1.40 € | |
| 035 | Cushion Ring MAKITA 421955-0 | 421955-0 | Pole laos | 1.00 € | |
| 036 | O Ring Case MAKITA 324216-6 | 324216-6 | Pole laos | 4.21 € | |
| 037 | O-Ring 9 MAKITA 213073-6 | 213073-6 | Laos | 1.00 € | |
| 038 | Ring Spring 28 MAKITA 233917-4 | 233917-4 | Pole laos | 0.99 € | |
| 039 | Striker MAKITA 324214-0 | 324214-0 | Pole laos | 2.81 € | |
| 040 | O-Ring 16 MAKITA 213227-5 | 213227-5 | Pole laos | 0.99 € | |
| 041 | Piston Cylinder MAKITA 318132-2 | 318132-2 | Pole laos | 19.64 € | |
| 042 | Flat Washer 12 MAKITA 267104-3 | 267104-3 | Pole laos | 0.99 € | |
| 043 | Piston Joint MAKITA 324215-8 | 324215-8 | Pole laos | 1.40 € | |
| 044 | Flat Washer 12 MAKITA 267104-3 | 267104-3 | Pole laos | 0.99 € | |
| 045 | O-Ring 63 MAKITA 213727-5 | 213727-5 | Pole laos | 2.81 € | |
| 046 | Ball Bearing 606 ZZ MAKITA 211012-0 | 211012-0 | Pole laos | 4.21 € | |
| 046-1 | Toode pole süsteemis | 210028-2 | – | – | – |
| 047 | Retaining Ring MAKITA 961003-8 | 961003-8 | Pole laos | 0.99 € | |
| 048 | Compression Spring 7 MAKITA 233343-7 | 233343-7 | Pole laos | 0.99 € | |
| 049 | Spur Gear 10 MAKITA 227179-4 | 227179-4 | Pole laos | 8.42 € | |
| 050 | Cam Shaft MAKITA 324668-1 | 324668-1 | Pole laos | 11.22 € | |
| 051 | Clutch Cam MAKITA 331992-5 | 331992-5 | Pole laos | 5.61 € | |
| 052 | Toode pole süsteemis | 219014-0 | – | – | – |
| 052-1 | Swash Bearing 10 MAKITA 219021-3 | 219021-3 | Pole laos | 14.03 € | |
| 053 | Helical Gear 25 MAKITA 226632-7 | 226632-7 | Pole laos | 5.61 € | |
| 053-1 | Helical Gear 25 MAKITA 226985-4 | 226985-4 | Pole laos | 1.53 € | |
| 054 | Hex Socket Head Bolt M4 × 12 MAKITA 266273-7 | 266273-7 | Pole laos | 0.99 € | |
| 055 | Bearing Retainer MAKITA 345179-3 | 345179-3 | Pole laos | 0.99 € | |
| 056 | Flat Washer 8 MAKITA 267234-0 | 267234-0 | Pole laos | 0.99 € | |
| 057 | Ball Bearing 608ZZ MAKITA 211032-4 | 211032-4 | Laos | 1.68 € | |
| 057-1 | Ball Bearing 608ZZ MAKITA 210029-0 | 210029-0 | Pole laos | 1.12 € | |
| 058 | Ring 8 MAKITA 324212-4 | 324212-4 | Pole laos | 2.81 € | |
| 059 | Stop Ring MAKITA 961011-9 | 961011-9 | Laos | 0.99 € | |
| 060 | Flat Washer 5 MAKITA 941102-2 | 941102-2 | Pole laos | 0.99 € | |
| 061 | Compression Spring 6 MAKITA 233342-9 | 233342-9 | Pole laos | 0.99 € | |
| 062 | Change Plate MAKITA 345363-0 | 345363-0 | Pole laos | 1.00 € | |
| 063 | Inner Housing Complete MAKITA 141574-3 | 141574-3 | Pole laos | 14.03 € | |
| 065 | O-Ring 26 MAKITA 213407-3 | 213407-3 | Pole laos | 0.99 € | |
| 066 | Oil Seal 10 MAKITA 213077-8 | 213077-8 | Pole laos | 4.21 € | |
| 067 | Ball Bearing 6000 DDW MAKITA 210059-1 | 210059-1 | Laos | 5.61 € | |
| 068 | Flat Washer 10 MAKITA 267213-8 | 267213-8 | Pole laos | 0.99 € | |
| 069 | Fan 64 MAKITA 240092-9 | 240092-9 | Pole laos | 1.00 € | |
| 070 | Armature Assembly MAKITA 519226-8 | 519226-8 | Pole laos | 30.87 € | |
| 071 | Flat Washer 7 MAKITA 253823-7 | 253823-7 | Pole laos | 0.99 € | |
| 072 | Ball Bearing 627 DDW MAKITA 210023-2 | 210023-2 | Pole laos | 2.81 € | |
| 073 | Wave Washer 15 MAKITA 267816-8 | 267816-8 | Pole laos | 0.99 € | |
| 074 | Toode pole süsteemis | 815J32-2 | – | – | – |
| 075 | Toode pole süsteemis | 188577-6 | – | – | – |
| 076 | Yoke Unit MAKITA 638020-0 | 638020-0 | Pole laos | 16.84 € | |
| 077 | Toode pole süsteemis | 638926-2 | – | – | – |
| 079 | Tapping Screw PT 4 × 18 MAKITA 266326-2 | 266326-2 | Pole laos | 0.99 € | |
| 080 | Pan Head Screw M3 × 10 MAKITA 911011-9 | 911011-9 | Pole laos | 0.99 € | |
| 081 | Heat Sink MAKITA 689070-8 | 689070-8 | Pole laos | 2.81 € | |
| 082 | Toode pole süsteemis | 188577-6 | – | – | – |
| 084 | Holder Cap MAKITA 643829-7 | 643829-7 | Laos | 0.99 € | |
| 085 | Carbon Brush CB-441 MAKITA 194435-6 | 194435-6 | Pole laos | 5.61 € | |
| 085-1 | Carbon Brush CB-441 MAKITA 195022-4 | 195022-4 | Laos | 5.61 € | |
| 086 | Switch Cover MAKITA 424111-1 | 424111-1 | Laos | 1.40 € | |
| 087 | Forward Reverse Change Lever MAKITA 450615-7 | 450615-7 | Pole laos | 0.99 € | |
| 088 | Toode pole süsteemis | 650655-7 | – | – | – |
| 090 | Tapping Screw PT 4 × 18 MAKITA 266326-2 | 266326-2 | Pole laos | 0.99 € | |
| 091 | Terminal MAKITA 644808-8 | 644808-8 | Pole laos | 5.00 € | |
| 092 | Battery Housing Set MAKITA 187212-3 | 187212-3 | Pole laos | 11.22 € | |
| 093 | Toode pole süsteemis | 263036-2 | – | – | – |
| 094 | Pin 1.5 MAKITA 268184-2 | 268184-2 | Pole laos | 0.99 € | |
| 095 | Battery Housing Set MAKITA 187212-3 | 187212-3 | Pole laos | 11.22 € | |
| 096 | Tapping Screw PT 4 × 18 MAKITA 266326-2 | 266326-2 | Pole laos | 0.99 € | |
| 097 | Cushion Rubber MAKITA 424042-4 | 424042-4 | Pole laos | 2.81 € | |
| 098 | Cushion MAKITA 424476-1 | 424476-1 | Pole laos | 0.99 € | |
| 099 | Cushion Rubber MAKITA 424042-4 | 424042-4 | Pole laos | 2.81 € | |
| 100 | Toode pole süsteemis | 815J42-9 | – | – | – |
| 101 | Tool Holder Assembly MAKITA 123100-0 | 123100-0 | Pole laos | 44.90 € |
